Rapid Product Freezing
Refrigeration capacity and airflow are selected to support the required product pull-down time and freezing process.
Blast freezers designed and installed in the size and configuration your project requires.
A blast freezer is designed to remove heat from products rapidly using a suitably engineered refrigeration system and controlled air circulation. Compared with ordinary frozen storage, blast freezing is designed around the product's initial temperature, target temperature, batch weight, required freezing time and loading pattern.
Mana Cold Room develops blast freezer cold rooms for commercial and industrial applications. Each installation should be sized for the actual operating conditions rather than room volume alone.
Refrigeration capacity and airflow are selected to support the required product pull-down time and freezing process.
Compressor, condenser, evaporator and controls are selected according to the calculated load and specified operating conditions.
Panel thickness, floor insulation, door construction and vapour control are considered for the room temperature and site conditions.
Our blast freezer designs can be adapted to a range of commercial food production and industrial freezing requirements.
The freezing method and operating cycle must be selected for the particular product, packaging, food safety process and production rate.
Correct equipment selection requires a heat-load calculation and confirmation of the intended freezing cycle. Room dimensions alone cannot establish the required compressor horsepower.
The final refrigeration unit should be selected from manufacturer capacity data at the specified evaporating and condensing conditions, with appropriate engineering allowances.
Blast freezing systems may operate at low air temperatures, often around -35°C to -45°C depending on the application and equipment design. This range is indicative, not a universal setting for every product or room. Product core temperature and required freezing time must be specified separately from the room air temperature.
| Design consideration | What must be established |
|---|---|
| Operating temperature | Required air temperature and product core target |
| Insulated panels | Thickness, thermal performance and vapour sealing |
| Floor and door | Floor insulation, loading conditions and door configuration |
| Refrigeration unit | Calculated load and verified capacity at design conditions |
| Airflow and loading | Product spacing, rack layout and uniform air distribution |
Final insulation, floor heating where required, refrigeration capacity and temperature settings should be determined by the project engineer.
Mana Cold Room provides customized cold room and refrigeration project services for businesses in Dubai, Abu Dhabi, Sharjah, Ajman, Al Ain, Ras Al Khaimah, Fujairah and Umm Al Quwain.
Confirm site dimensions, product requirements, batch loading and the freezing cycle.
Assess heat load, insulation, airflow, refrigeration components and controls.
Install the system, verify operation and commission against agreed project requirements.
Explore related Mana Cold Room services and equipment.
A blast freezer is a refrigeration room designed to freeze products rapidly using controlled low-temperature air circulation and sufficient refrigeration capacity for the required batch and freezing time.
Some blast freezing applications use air temperatures around -35°C to -45°C. The correct setting depends on the product, freezing process, equipment capacity and required product core temperature.
First calculate the total refrigeration load, including product cooling and freezing, room heat gain, infiltration, fans and other loads. Convert the required capacity to a suitable compressor model using manufacturer performance data at the intended evaporating and condensing conditions. Horsepower alone is not a reliable measure of refrigeration capacity.
Yes. A system can be designed around product type, batch weight, entry temperature, packaging, loading arrangements, target core temperature and required freezing time.
Mana Cold Room provides cold room design, refrigeration installation and related project services across Dubai and the UAE. Contact the team with your project specifications to discuss availability and requirements.
Provide the room dimensions, product type, kilograms per batch, product entry temperature, target core temperature, required freezing time, daily production, ambient conditions and site location.
Tell us your room dimensions, product type, batch weight and required freezing time. Our team can review your project requirements.
